Monoclinic Nano Zirconia, Zirconium Dioxide powder ZrO2 nanopowder/nanoparticles

Short Description:

1. Product name: zirconium dioxide ZrO2
2.Purity: 99.9% min
3.Appearacne: White powder
4.Particle size: 20nm, 50nm, 1-5um, etc
5.Application: applied in the products and industries as following: sophisticated ceramics, electronic components, additives.
Contact: Cathy Jin
Email: Cathy@shxlchem.com
Tel: +8618636121136 (Wechat/ Whatsapp)


Product Detail

Product Tags

Product Description

Brief introduction:

Nano zirconia has the characteristics of high temperature resistance, good chemical stability, and good material composites. Composite of nano zirconia with alumina and silica can improve the performance parameters of the material. Nano zirconia is not only applied in the fields of structural ceramics and functional ceramics. Utilizing the conductive properties of different elements doped with nano zirconia for electrode manufacturing in solid state batteries.

Product name Nano zirconium dioxide Zro2
Purity 99.9% min
Cas 1314-23-4
Appearacne White powder
Particle size 20nm, 50nm, 100nm ,200nm,1-5um, or customized.
Product characteristics insoluble in water, hydrochloric acid, and dilute sulfuric acid
MF ZrO2
MW 123.22
MP 2700℃
BP 4300℃
Density 5.85g/cm3
Mohs hardness  7
Crystal form Monoclinic
Specific surface area 15-50m2/g
Brand Xinglu

Specification:

Item XL-ZrO2-001 XL-ZrO2-002
Crystal form Monoclinic Monoclinic
Particle size 20-30nm 200n
Specific surface area 50m2/g 30m2/g
ZrO2% (+ HfO2) >99.9 >99.9
Al2O3% ≤ 0.002 0.002
SiO2%≤ 0.002 0.002
Fe2O3%≤ 0.003 0.003
CaO%≤ 0.003 0.003
MgO%≤ 0.003 0.003
TiO2%≤ 0.001 0.001
Na2O%≤ 0.001 0.001

Note: Particle size, specific surface area, surface coating modification, etc. can be customized according to customer requirements.

Application:

1). Zirconia can act on refractory materials: electronic ceramic sintering support plates, molten glass, refractory materials for metallurgical metals, zirconium tubes
2). Nano zirconia used for catalysts and automotive exhaust purification catalysts
3). Nano zirconium oxide has a large specific surface area, high strength, strong oxygen storage capacity, good thermal stability and low-temperature oxidation effect
4). Nano zirconium dioxide used for battery material modification and oxide fuel cells
5). Nano zirconium dioxide  used as a raw material for ceramic slurries such as MLCC
7). Nano zirconium dioxide can used for Lithium battery material additives.
8). Functional ceramics, structural ceramics: electronic ceramics, bioceramics, sensor ceramics, magnetic materials, etc;
9). Piezoelectric components, oxygen sensitive resistors, large capacity capacitors;
10). Artificial gemstones, grinding materials. Functional coating materials: added to the coating have anti-corrosion and antibacterial effects, improving wear resistance.
11). Nano zirconia improves the toughness, surface smoothness, and ceramic density of ceramic structural components.
12). High strength, high toughness and wear-resistant products: mill lining, wire drawing die, hot extrusion die, nozzle, valve, ball, pump parts, various sliding components, etc.
